- Place of Origin: China
- Brand Name: glorystar
- Model Number: GS-200M
Product Features
● Machine structure frame precisely welded by CO2, high temperature annealing treatment to ensure normally to run without deforming. The model is mainly designed for the mold industry for precision molds repair;
● Using the new high energy laser power, laser source, high flow water machine;
● High welding energy , compared to the general welding machine, thicker fusible wire, welding stable performance;
● Single laser pulse, waveform can be adjusted to meet the complex requirements of special materials, welding technology.
Product Features
● Touch-screen interface, easy operation, compact and portable.
● Welding points strong and beautiful, small heat-affected zone, the weld smooth and no holes, weld strength, high toughness.
● Minor parts of precision welding, spot welding and a variety of different parts of the mould repair welding etc.
- Place of Origin: China
- Brand Name: glorystar
- Model Number: GS-200M
Technical Data
| Model No. | GS-200M | GS-180M |
| Max. Laser power | 200W（optional） | 180W（optional） |
| Laser wavelength | 1064nm | 1064nm |
| Max pulse energy | 70J | 60J |
| Frequency | 0.1-100Hz | 0.1-100Hz |
| Pulse width | 0.1-20MS | 0.1-20MS |
| Welding depth | 0-1mm | 0-1mm |
| Beam range | Φ0.2-2.0mm | Φ0.2-2.0mm |
| Working area | 450x350mm | 450x350mm |
| Power consumption | ≤6KW | ≤5.5KW |
| Power Requirement | 380V 50Hz (60Hz) / 220V 50Hz (60Hz) | 380V 50Hz (60Hz) / 220V 50Hz (60Hz) |
| Control system | Microcomputer program control | Microcomputer program control |
| Water cooling | 1PWater cooling 1P | 0.6P Water cooling 0.6P |
| Observing system | CCD/microscope | CCD/microscope |
| Output laser focus | 110mm | 110mm |
| Up and down size | 500mm | 500mm |
| Work bench bearing | 100Kg | 100Kg |
| Weight | 110Kg | 100Kg |
| Size | 550*1200*1280mm | 550*1200*1280mm |
